- Human body and Vehicle detection
- Detection,Privacy Mask,Flip,Rotate
- Strong water-proof housing, IP67
- 1/2.8" Sony CMOS sensor
| Camera | |
|---|---|
| Image Sensor |
1/2.8" Sony CMOS |
| Resolution | 8 megapixels |
| Electronic Shutter | AUTO, 1/25s ~ 1/100000s |
| Min. Illumination | 0.01Lux@F1.2(AGC ON), 0Lux IR on |
| Day/Night | Auto/Color/(B/W)/Timing |
| WDR | Digital WDR |
| White Balance | Auto/Manual |
| BLC /HLC | Support |
| DNR | 2D/3D DNR |
| Other | Human body and Vehicle detection,AGC,MotionDetection,Privacy Mask,Flip,Rotate,RIO,OSD overlay |
| Encode | |
|
Video Standard |
H.264/H.265 |
| Video Resolution | MainStream:20fps@8MP(3840x2160), 30fps@6MP(3072x2048)/5MP(2592x1944) /4MP/3MP/1080P/720P,etc. |
| Sub stream | 720x480/VGA(640x480)/360P/ QVGA@30fps,etc. |
| Video Bitrates | 512Kbps - 12Mbps, VBR/CBR |
|
OSD Overlay |
Title and Time overlay ,custom color adjustable |
|
IR Led |
18 pcs SMD IR Led |
| Infrared Distance | 82ft |
| Focal length | HD 2.8/3.6/6 mm fixed lens optional,default in 3.6mm , if need 2.8mm , need add 1USD per piece |
| IR Power On | Auto Control |
| Network | |
| Protocol | HTTP/RTSP/FTP/SMTP/ DHCP/NTP/NFS |
| P2P. | Yes |
| Web | IE , Firefox,Edge, Google Chrome |
| Media | CMS, Android, IOS |
| ONVIF | 17.06 compatible |
| General | |
| Network Port | 1-RJ45, 100Mbps, POE |
| Power Supply | 12 VDC ± 10%,POE |
| Operating Temp | -86°F-(+140°F), 10%-90%RH |
